GNEE STEEL supply high quality Cold Rolled Steel Plates. We are one of China's leading steel mill manufacturers, and we promise our customers reliable quality, quick delivery and excellent post-sales service. Special standards and grades can be manufactured according to customer requirements.
1.Product name: cold rolled steel plate
2.Grade: SPCC, SPCD, SPCE, DC01-06, St12, Super deep drawing,etc.
3.Standard: JIS G3141-1996, EN 10131-2006, DIN EN 1002
4.Thickness: 0.20mm - 3.0mm
5.Width: 600/1000/1250/1500 (mm) or per customer's request
6.Length: Customized per customer's request
| Standard | Designation | Delivery condition | Symbol | Yield strength (MPa), 0.2 % offset | Tensile strength (MPa) | Elongation, A80, ≥ % | Elongation, A50, ≥ % | Hardness, HV | Validity of the mechanical properties |
| EN 10139 | DC01 (1.0330) | Annealed | A | – | 270 – 390 | 28 | 30 | ≤ 105 | 3 months |
| Skin passed | LC | ≤ 280 | 270 – 410 | 28 | 30 | ≤ 115 | |||
| Work hardened | C290 | 200 – 380 | 290 – 430 | 18 | 20 | 95-125 | |||
| C340 | ≥ 250 | 340 – 490 | Not required | Not required | 105-155 | ||||
| C390 | ≥ 310 | 390 – 540 | 117-172 | ||||||
| C440 | ≥ 360 | 440 – 590 | 135-185 | ||||||
| C490 | ≥ 420 | 490 – 640 | 155-200 | ||||||
| C590 | ≥ 520 | 590 – 740 | 185-225 | ||||||
| C690 | ≥ 630 | ≥ 690 | ≥ 215 |
