Galvanized Corrugated Roofing Sheet is a kind of profiled plate which is made of galvanized coated steel plate and formed into various wave shapes by rolling and cold bending.
Dx51d Prepainted Galvanized Corrugated Roofing Sheet Specification
| Product Name | Dx51d Prepainted Galvanized Corrugated Roofing Sheet |
| Material | DX51D Galvanized Steel |
| Color | RAL Color or as request |
| Spangle | Zero,Small,Large,Mini |
| Width Range | 600mm-1575mm,etc |
| Thickness Range | 0.15mm-2.0mm |
| Zinc Coating | 40g-275g |
| Topcoat Types | Polyester (PE), Silicone Polyester (SMP), High Durable Polyester (HDP), Fluoropolymer (PVDF) |
| Paint Coating Thickness Range | Front Coating: primer+topcoat: 10um to 40um;Back/Bottom Coating: 3um to 10um. |
| Coil ID | 508mm/610mm |
| Coil Weight | 3 metric tons to 5 metric tons |
| Applications | Construction Use |
Galvanized Corrugated Roofing Sheet Size Type
Type | Effective Width/Full Width(mm) | Feeding Width(mm) | Thickness(mm) |
FX28-207-828 | 828/935 | 1000 | 0.1-0.8 |
FX23-183-1100 | 1100-1180 | 1250 | 0.1-0.8 |
FX27-190-950 | 950/1040 | 1200 | 0.1-0.8 |
FX35-185-740 | 740/800 | 960 | 0.1-0.8 |
FX30-152-760 | 760-820 | 980 | 0.1-0.8 |
FX25-210-630 | 630/680 | 750 | 0.1-0.8 |
FX25-210-840 | 840/890 | 1000 | 0.1-0.8 |
FX35-125-750 | 750/820 | 1000 | 0.1-0.8 |
FX50-410-820 | 820/840 | 1000 | 0.1-0.8 |
FX75-200-600 | 600/650 | 1000 | 0.1-0.8 |
FX76-150-688 | 688/750 | 1000 | 0.1-0.8 |
FX15-225-900 | 900/940-950 | 1000 | 0.1-0.8 |
FX28-205-820 | 820/910 | 1000 | 0.1-0.8 |
FX12-110-880 | 880/900-910 | 1000 | 0.1-0.8 |
FX-25-205-1025 | 1025/1100 | 1200 | 0.1-0.8 |
Prepainted Galvanized Corrugated Roofing Sheet Feature
PPGI Corrugated Sheets is a unique building material. It has the characteristics of light weight, high strength, rich color, convenient construction, earthquake resistance, fire prevention, rain proof, long service life and maintenance free, and has been widely applied.
Prepainted Galvanized Corrugated Roofing Sheet Package:
Waterproof paper,galvanized steel covered and steel strip packed with iron pallet
1.Shipping time: 15-30 days after receive deposit
2.Shipping way: container transport
20 feet container contains dimension;Width under 2300mm, length under 6000mm;
40 feet container contains dimension;Width under 2300mm, length under 12000mm
