The corrugations increase the bending strength of the Corrugated Roofing Sheet in the direction perpendicular to the corrugations, but not parallel to them. Normally each sheet is manufactured longer in its strong direction.
JIS G3302 PPGI Corrugated Roofing Sheet Parameters
| Commodity | JIS G3302 PPGI Corrugated Roofing Sheet |
| Techinical Standard: | JIS G3302-1998, EN10142/10137, EN 10169 |
| Grade | SGCC, DX51D / DX52D / S250, 280GD,S350GD,G550,SGC400,SGC440 |
| Types: | For general / drawing use |
| Thickness | 0.15-1.5 mm |
| Zinc coating | Z60-150 g/m2 |
| Spanglet: | No/ small/ big regular |
| Surface treament: | Chromed passivation, anti-finger print, skinpassed |
| Sheet weight: | 3-5MT |
| Profile model: | YX14-65-825/ YX18-76.2-836 / YX14-63.5-825 / |
| YX35-125-750 / YX15-225-900 / YX10-125-875 / | |
| YX12-110-880 / YX25-210-840 / YX25-205-820(1025) | |
| Substrate: | cold rolled sheet |
| Application: | Roof, walls, internal and external decorating materials, building etc |
JIS G3302 PPGI Corrugated Roofing Sheet Property
Steel Grade | Chemical Composition (%) | Mechanic Property | C.B of Coating | Coating | ||||||
| C | Si | Mn | S | P | T.S | Y.S | E.L | |||
| x10-2 | x10-2 | x10-2 | x10-2 | x10-2 | MPA | MPA | % | D=0 180° | G/M2 | |
| JIS G3302 SGCC | 12 | 30 | 41 | 31 | 21 | 480 | 300 | 13 | OK | Z60-150 |
| JIS G3302 SGCH | 12 | 10 | 21 | 18 | 8 | 680 | 650 | OK | Z60-150 | |
JIS G3302 PPGI Corrugated Roofing Sheet FAQ
Q: What thickness do you have?
A: Our main thickness are 0.12~0.8mm
Q: What is the biggest zinc coating you have?
A: we have zinc coating 30~275g/m2, the cheapest one is 30g/m2
Q: What is the price?
A: Prices are different according to your specifications, quantity and surface treatment. The thinner the thickness is, the higher the price are.Meanwhile, the thicker the zn/az coating is, the higher the prices are.
