PPGL roofing corrugated sheet is also called profiled sheet. It is made of colored coated steel sheet, galvanized sheet and other metal sheets. It is roll-formed into various wave-shaped profiles.
PPGL Color Corrugated Roof Sheet Specification
Name | PPGL Color Corrugated Roof Sheet | ||
| Width | 600-1100 mm | Thickness | 0.10 -1mm |
Length | 2-5 m | Tolerance | Thickness:+/-0.02mm |
Paint type | PE or PVDF | Width:+/-2mm | |
Zinc coating | 30g/m2-275g/m2 | Color Coating | Top:15-25µm/Back:5-8µm |
Weight of each package | 3 mt/As request | Hardness | Full hard/soft/As request |
Depth of corrugated | From 15mm to 18mm | Pitch | From 75mm to 78mm |
Yield strength | 550MPA/As request | Tensile strength | 600MPA/As request |
Material | SGCC,SGCH,JIS G3302,DX51D,DX52D,DX53D | ||
Certification | ISO 9001-2008,SGS,CE,BV | ||
Grade | CGCC/SGCC/SGCH/SPCC | ||
Colors | Refer to RAL numbers or customer sample,common colors are sea blue, white grey and bright red. | ||
Surface treatment | Unoil,dry,chromate passivated,non-chromate passivated | ||
Standard | GB/T12754-2006;ASTM A 755;EN 10169;JIS G3312;AISI;BS;DIN | ||
Corrugated Sheet Raw Materials | Galvanized steel, Aluzinc Steel,Aluzinc Pre-painted sheet and Aluminium sheet. | ||
Technique | Cold rolled—>hot dipped galvanizing—>Color Coated—>corrugated | ||
Gloss | The gloss can changeable by Customers' Request.we can also do some High gloss. | ||
Application | Various roofs or walls referring to the large size factory buildings,storage,exhibition halls,gymnasiums etc. | ||
PPGL Color Corrugated Roof Sheet Advantage
1.Light material &good durability
2.Lifespan is as long as 30 years, anti-corrosion for zinc coating ensure its' excellent lifespan
3.Excellent waterproof, it is seamless, making 100%waterproof.
4.Cost effective: it is easy to install, so that it can decrease the construction, increase construction effectiveness.
5.Various colours: we can make any colour for you. paint will not crack, peel or fade, it does not need repainting.
6.Resistance to strong wind.
Application:
PPGL Color Corrugated Roof Sheet is suitable for Roof, wall and interior and exterior wall decoration of steel structure houses.
PPGL Color Corrugated Roof Sheet Packing:
Packaging: In bundle with steel strip or packed in wooden pallets or as customers' requirement.
Shipping:We have long-term cooperation with many experienced shipping companies and will find the most suitable mode of transportation for you.
