Coated Aluminum Coil Ste

Coated aluminum coil (PPAL) is widely used in the roofing and cladding system, ceiling system, curtain wall plate, shutter, gutter, composite panel, can, home appliances board and embossed aluminium coil. The Process of Coil Coating Coil coating is a continuous and highly automated process for coating metal before fabrication.

SUBSTRATE

SUBSTRATE
Mill finish tension leveled Aluminum coils.
QUALITY
Smooth surface, Mill Finish Aluminum coils.
STANDARD
ASTM B209 M or any other international standards
ALLOY
1100, 3004, 3005 , 3105 , 5005,5050,5052 etc.., or any other alloy on request
TEMPER
H -16, H – 26, H – 46, H – 48

THICKNESS
0.20 mm – 1.20 mm for Aluminium
WIDTH
40 mm – 1350 mm
INTERNAL DIA.
508 mm – Standard
610 mm – Optional
OUTER DIA.
1800 mm Max

As per types of surface coating of paint, color coated aluminum coils can be divided into polyester (PE) coated aluminum coil, fluorocarbon (PVDF) coating aluminium coil and Epoxy coated aluminum coil.

According to the thickness of the coating, it can be divided into single-coated aluminium coil (4-20 microns); double-coated aluminum coil (25 to 28 micron) and triply-coated aluminum coil (35-38 micron).

Prepainted aluminum coils

Product Name	Pre-painted Aluminum Coil
Material Thickness	0.17mm-1.2mm
Material Width	600mm-1350mm
Paint	KCC / NIPPON / Valspar / AXALTA... .etc
Color	RAL Color & Customized
Coil Inside Dia.	508mm/610mm
Coil Weight	1-3MT
Packing	Standard Seaworthy Packing & Customized
