B35P115 Electrical steel
The "115" in B35P115 refers to the specific value of the magnetic induction, measured in tesla, that the steel can support under a certain magnetic field strength. In other words, it indicates the magnetic performance of the silicon steel.
Overall, B35P115 is a specific type of grain-oriented silicon steel with high magnetic flux density and a nominal thickness of 0.35 millimeters. It is designed for use in high-performance electrical equipment that requires excellent magnetic properties.
B35P115 steel Mechanical Properties
|
Grade |
Nominal thickness（mm） |
tensile strength L（N/mm2） |
Yield Strength L（N/mm2） |
Elongation L（%） |
Hardness HV1 |
Bending frequency (times) |
Stacking factor（%） |
|
B35P115 |
0.35 |
350 |
310 |
11 |
195 |
17 |
98.0 |
NOTE:.
a detector according to GB / t228-2002, GB / T 19289-2003
b. above are typical values only for reference does not guarantee
c. L direction refers to the rolling direction
B35P115 steel sheet/plate Electromagnetic induction standard
|
Grade |
Nominal thickness（mm） |
Theoretical density（kg/dm3） |
Maximum core loss P17/50 |
minimum magnetic induction B8 |
|
B35P115 |
0.35 |
7.65 |
1.15 |
1.88 |
