Mechanical Properties of 347 Stainless Steel Pipes
Room Temperature Tensile Properties
Minimum mechanical properties of the stabilized Alloys 321 and 347 chromium-nickel grades in the annealed condition (20000F [10930C], air cooled) are shown in the table.
elevated Temperature Tensile Properties
Typical elevated temperature mechanical properties for Alloys 321 and 347 sheet / strip are shown below. Strength of these stabilized alloys is distinctly higher than that of non-stabilized 304 alloys at temperatures of 10000F (5380C) and above.
High carbon Alloys 321H and 347H (UNS32109 and S34700, respectively) have higher strength at temperatures above 10000F (5370C). ASME maximum allowable design stress data for Alloy 347H reflects the higher strength of this grade in comparison to the lower carbon Alloy 347 grade. The Alloy 321H is not permitted for Section VIII applications and is limited to 8000F (4270C) use temperatures for Section III code applications.
347 SS Pipes Mechanical Properties
| Grade | 347 | |
|---|---|---|
| Tensile Strength (MPa) min | 515 | |
| Yield Strength 0.2% Proof (MPa) min | 205 | |
| Elongation (% in 50mm) min | 40 | |
| Hardness | Rockwell B (HR B) max | 95 |
| Rockwell B (HR B) max | 201 |
