DC01 Cold Rolled Steel
What is DC01 Steel?
DC01 steel is a low-carbon, cold-rolled steel grade specified in the EN 10130 standard, suitable for cold-rolled flat products made from unalloyed low-carbon steel. "DC" stands for "Drawing Cold," indicating its suitability for cold forming applications; "01" represents the base grade in the series, offering standard formability and surface quality suitable for general engineering and manufacturing applications.
DC01 steel, or 1.0330, is a non-alloy quality steel with low carbon. Made as flat sheets by cold rolling, it has a smooth surface and good formability. Types include DC01-A, DC01-B, and electro-galvanized DC01+ZE (1.0330+ZE) under EN 10152. Related standards are EN 10130 and EN 10131. Variants DC03 to DC07 offer better formability. It is used for automotive parts, appliances, and metal products.
DC01 steel Mechanical properties
| Grade |
Material No. |
Yield Strength MPa Max |
Tensile strength MPa |
Elongation% min A80 |
R90 |
n90 |
|
DC01 |
1.0330 |
280 |
270-410 |
28 |
- |
- |
DC01 Steel Equivalent Grades
| Standard | Equivalent Grade |
| EN (EU) | DC01 (1.0330) |
| USA (SAE) | SAE1008, SAE1010 |
| Germany (DIN/WNr) | St12, FeP01 |
| Japan (JIS) | SPCC |
| France (AFNOR) | F12, FeP01 |
| England (BS) | CR4, FeP01 |
| Italy (UNI) | FeP01 |
| Spain (UNE) | AP00 |
| China (GB) | 08, 08F |
| Austria (ONORM) | St02Z |
| Russia (GOST) | 08kp, 08ps |
| ISO | CR1, CR22 |
DC01 Steel Chemical Composition
| Element | Content (%) |
| Carbon, C | ≤ 0.12 |
| Manganese, Mn | ≤ 0.60 |
| Phosphorus, P | ≤ 0.045 |
| Sulfur, S | ≤ 0.045 |
| Silicon, Si | ≤ 0.03 |
| Nitrogen, N | ≤ 0.008 |
| Aluminum, Al | ≤ 0.02 |
| Copper, Cu | ≤ 0.20 |
How Does DC01 Steel Perform Under High-Temperature Conditions?
DC01 steel is primarily suitable for cold forming and has limited performance at high temperatures, which reduce its strength and formability. However, GNEE STEEL's DC01 steel has optimized the cold rolling process to ensure that it has excellent strength and toughness at room temperature, making it particularly suitable for precision machining and everyday applications.
Other cold rolled steel in EN 10130
DC01 – This grade can be used for simple forming work, e.g. bending, embossing, beading and drawing.
DC03 – This grade is suitable for forming requirements such as deep drawing and difficult profiling.
DC04 – This grade is suitable for high forming requirements.
DC05 – This deep-drawing grade is suitable for higher forming requirements.
DC06 – This special deep-drawing grade is suitable for the highest forming requirements.
DC07 – This super deep-drawing grade is suitable for extreme forming requirements.
