B50A800 Non-oriented Silicon Steel
B50A800 steel Mechanical Properties
Grade | Nominal thickness（mm） | tensile strength L（N/mm2） | Yield Strength L（N/mm2） | Elongation L（%） | Hardness HV1 | Bending frequency (times) | Stacking factor（%） |
B50A800 | 0.50 | 7.80 | 397 | 266 | 38 | 126 | ≥15 |
B50A800 steel plate/sheet Electromagnetic induction standard
Grade | Nominal thickness（mm） | Theoretical density（kg/dm3） | Maximum core loss P17/50 | minimum magnetic induction（T） |
B50A800 | 0.50 | 7.80 | 8.00 | 1.70 |
| Product Name | B50A800 Non-oriented Silicon Steel |
| Technical Standard | EN10147/EN10142/DIN 17162/JIS G3302/ASTM A653 |
| Grade | Grain oriented steel 27QG100/27QG110/27Q120/27Q130/27Q140/30QG110/30QG120/30QG130/30Q130/30Q140/30Q150/30QG125/35QG135/35Q135/35Q145/35Q155/35Q165 Non-oriented steel 35W230/35W250/35W270/35W300/35W330/35W360/35W400/35W440/50W230/50W250/50W270/50W290/50W310/50W330/50W350/50W400/50W470/50W540/50W600/50W700/50W800/50W1000/50W1300/65W600/65W700/65W800/65W1000/65W1300/65W1600 M350-50A/M400-50A/M470-50A/M530-50A/M600-50A/M700-50A/M800-50A/M940-50A/M310-65A/M350-65A/M400-65A/M470-65A/M530-65A/M700-65A/M800-65A/M1000-65A/M600-100A/M700-100A/M800-100A/M1000-100A/M1300-100A |
| Type | Coil/Sheet/Plate/Strip |
| Thickness | 0.12-6.00mm,or customer's requirement |
| Width | 600mm-1500mm,according to customer's requirement |
| Application | Transformer Core/Power Transformers/Electrical Products, etc. |
Widely used in transformers, generators, various household motors and micro-motors, etc.
