Material and coating: Z180 means the weight of double-sided zinc layer is 180g/m², which is a hot-dip galvanized sheet with medium zinc layer thickness. Common materials include DX51D+Z (standard structural steel) and SGCC (Japanese standard galvanized sheet).


• Production Process

Alkaline degreasing: Use alkaline solution to remove oil and impurities on the surface of the steel coil to ensure the cleanliness of the base material.

‌Hydrochloric acid pickling: Use a hydrochloric acid solution with a concentration of 15%-20% to dissolve the oxide scale and rust. After pickling, rinse twice to remove the residual acid.

‌Plating treatment: Immerse in zinc ammonium chloride solution to form an activated film, enhance the bonding strength of the zinc liquid and the steel base, and prevent oxidation.

‌

Drying: Dry for more than 150 seconds at 120-200℃ to avoid splashing of zinc liquid during subsequent zinc dipping.

Annealing process: Remove the residual oil film on the surface through oxidation-reduction treatment and form a pure iron surface to improve the adhesion of the coating.

Hot-dip galvanizing: The temperature of the zinc liquid is strictly controlled at 450±5℃, and the steel coil is dipped into the zinc pot through a spiral mechanism to ensure uniform adhesion of the zinc liquid. The zinc dipping time is adjusted according to the coating requirements.

‌Coating control‌: Adjust the thickness of the zinc layer, blow away the excess zinc liquid with compressed air in the external blowing ring, and ensure the smoothness of the inner wall of the tube by internal blowing.

Post-plating treatment: After plating, the steel coil enters the 80℃ water cooling tank for cooling and shaping, and the circulating water system is treated for energy saving.

• Service and Support

Customized production: Supports fine-tuning of thickness, width, and zinc layer. Provides value-added services such as striping, lamination, and anti-rust oil coating.

Quality assurance system: Full process testing. Provide SGS report and material certificate.

Logistics: Global major port services, support third-party inspection.

In the wave of industrial material upgrades, hot dipped galvanized steel coil Z180 has become a strategic choice for enterprises to reduce costs and increase efficiency with its irreplaceable anti-corrosion performance and flexible application scenarios.

Contact us now to get professional material selection advice and industry success cases to help you gain an advantage in the competition!
