GNEE steel is a standard supplier of Stainless Steel 316 Flat Bars, which are designed in chemical etched patterns. SS 316 Flat Bars are often used for heat treating and nuclear reactor applications. Our offered range of Alloy 316 Flat Bars is extensively used in ship building industry, construction industry, petroleum, chemical and other industries. Due to high chromium and some aluminum content, good resistance in oxidizing sulfur bearing atmospheres at elevated temperatures is demonstrated in Grade 316 Flat Bars. Appreciated in the market owing to this their robustness, durability and high strength, these Type 316 Flat Bars are highly recommended.
ASTM A276 STAINLESS STEEL 316 FLAT BARS EQUIVALENT GRADES
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | AFNOR | EN |
| SS 316 | 1.4401 / 1.4436 | S31600 | SUS 316 | 316S31 / 316S33 | Z7CND17‐11‐02 | X5CrNiMo17-12-2 / X3CrNiMo17-13-3 |
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | Fe |
| SS 316 | 0.08 max | 2.0 max | 1.0 max | 0.045 max | 0.030 max | 16.00 - 18.00 | 2.00 - 3.00 | 11.00 - 14.00 | 67.845 min |
ASME SA276 STAINLESS STEEL 316 FLAT BARS MECHANICAL PROPERTIES
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 8.0 g/cm3 | 1400 °C (2550 °F) | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 35 % |
316 STAINLESS STEEL FLAT BAR SIZES
| SS 316 Flat bar sizes in mm | SS 316 Flat Bar Size (inch) | SS 316 Flat Bar Thickness (mm) | SS 316 Flat Bar Thickness (in Inches) |
| 22 | 7/8 | 17 & 18 | 2/3 - 5/7 |
| 25 | 1 | 5 to 20 | 3/16 - 4/5 |
| 30 | 1-3/16 | 5 to 20 | 3/16 - 4/5 |
| 32 | 1-1/4 | 6 to 20 | 1/4 - 4/5 |
| 35 | 1-3/8 | 5 to 20 | 3/16 - 3/16 |
| 40 | 1-4/7 | 5 to 25 | 3/16 - 1 |
| 45 | 1-7/9 | 5 to 25 | 3/16 - 1 |
| 47 | 1-6/7 | 17,25 & 32 | 2/3, 1 & 1-1/4 |
| 50 | 2 | 5 to 32 | 3/16 - 1-1/4 |
| 55 | 2-1/16 | 5 to 25 | 3/16 - 1 |
| 57 | 2-1/4 | 32 | 1-1/4 |
| 60 | 2-3/8 | 5 to 35 | 3/16 - 1-3/8 |
| 63 | 2-1/2 | 10 to 30 | 3/8 - 1-3/16 |
| 65 | 2-5/9 | 10 to 30 & 35 | 3/8 - 1-3/16, & 1-3/8 |
| 70 | 2-3/4 | 6 to 25 & 40 | 1/4 - 1, & 1-4/7 |
| 75 | 3 | 8 to 25 | 5/16 - 1 |
| 80 | 3-1/8 | 8 to 20 | 5/16 - 4/5 |
| 90 | 3-1/2 | 8 to 20 | 5/16- 4/5 |
| 100 | 4 | 8, 10, 12 | 5/16, 3/8, 1/2 |
316 stainless steel flat bar is normally used in natural gas/petroleum/oil, aerospace, food and beverage, industrial, cryogenics, architectural, and marine applications. 316 stainless steel bar has high strength and excellent corrosion resistance, including in marine or extremely corrosive environments. It is stronger, though less malleable and machinable than 304, 316 maintains its properties in cryogenic or high temperatures. 316 stainless steel flat bar stock is available in full size and custom cut lengths.
