Classification Of Aluminum Foil For Packaging
According to the application, it can be divided into
Aluminum foil for food packaging
Aluminum foil for pharmaceutical packaging
Aluminum foil for tabacco packaging
Aluminum foil for clothes packaging
Aluminum foil for packaging bag
Aluminum foil for flexible packing
Aluminum foil for laminated aluminum foil paper
Specifications Of Aluminum Foil For Packaging
1. Alloys And Tempers
| Alloy | Temper |
| 1060、1050、1235、1100、
3003、8011、8079 |
O、H14、H18、H19、
H22、H24, H26 |
2. Specifications And Tolerances
| Gaugemm | Widthmm | Gauge Tolerance% | Width Tolerancemm | IDmm | ODmm | CoreMaterial |
| 0.005-0.2 | 40-1650mm | +/-5% | +/-1 | 76, 152 | 100-950 | Aluminum |
Outer diameter measurement of aluminum foil big rolls
Production Process
Aluminum foil is produced by rolling aluminum slabs cast from molten aluminum in a rolling mill to the desired thickness of less than 0.2 mm. It provides a complete barrier to light, oxygen, moisture, and bacteria.
For this reason, foil is used extensively in food packaging and pharmaceutical packaging. It is also used to make aseptic packaging that enables the storage of perishable goods without refrigeration.
Performance Chart Of Aluminum Foil For Packaging
1. Chemical Composition
Here the chemical composition covers alloy 8011 or alloy 1235.
| Alloy | 8011 | 1235 | |
| Chemical Composition (max %) | Si | 0.50-0.9 | (Si+Fe):0.65 |
| Fe | 0.6-1.0 | ||
| Cu | 0.10 | 0.05 | |
| Mn | 0.20 | 0.05 | |
| Mg | 0.05 | 0.05 | |
| Cr | 0.05 | ------ | |
| Zn | 0.10 | 0.10 | |
| Ti | 0.08 | 0.06 | |
| Others | ------ | V:0.05 | |
| Al | Remainder | ≧99.35 | |
2. Mechanical Properties Of Aluminum Foil For Packaging For Various Purposes
| Product | Gauge | Alloy-Temper | Mechanical Properties Tensile Strength (Mpa) |
Elongation（δ%） |
| aluminium foil for blister packaging | 0.006-0.009 | 1235-O | 60～80 | ≥1.0 |
| ＞0.009-0.020 | 60～80 | ≥1.0 | ||
| ＞0.020-0.030 | 60～80 | ≥1.0 | ||
| 0.018-0.030 | 8011-H18 | ≥180 | ≥2.0 | |
| 0.009-0.08 | 8011-O | ≥75 | ≥3.0 | |
| Beer Bottle Wrapping Foil | 0.009-0.010 | 8011-O | 80～105 | ≥2.0 |
| ＞0.010-0.0115 | 80～105 | ≥3.0 | ||
| Toothpaste Tube Foil |
0.009-0.011 | 8011-O | ≥70 | ≥2.0 |
| 0.011-0.016 | ≥80 | ≥3.0 | ||
| 0.016-0.03 | ≥80 | ≥3.0 | ||
| Retort Pouch | 0.006-0.009 | 1235-O | 50～85 | ≥1.0 |
| Tetra Pack | 0.006-0.0066 | 1235-O | 55～70 | ≥1.0 |
| Cigarette Foil | 0.006-0.007 | 1235-O | 70～90 | ≥1.0 |
| Foil for Laminating with Paper Board |
0.006-0.007 | 1235-O | 50～70 | ≥2.0 |
| Container Foil | 0.030-0.130 | 3003-H24 | 140～190 | ≥6.0 |
| Hot Seal or Lidding Foil | 0.020-0.060 | 8011-O | 70～105 | ≥4.0 |
| Adhesive Tape Foil | 0.0065-0.012 | 1235-O | ≥50 | ≥1.5 |
| 0.010-0.050 | 8011-O | ≥55 | ≥2.0 | |
| Aluminum foil for food packaging | 0.010-0.050 | 8011-O 1235-O |
80～110 | ≥2.5 |
| Power Capacitor Foil |
0.005-0.009 | 1235-O | ≥60 | ≥1.0 |
| Cable Foil | 0.0065-0.050 | 1235-O 1145-O 8011-O |
40～80 | ≥2.0 |
| Fin Stock | 0.08-0.20 | 8011-H24 1100-H26 |
130～160 | ≥5.0 |
Packaging And Shipping Requirements For Jumbo Rolls Of Aluminum Foil
1. Quantities
As specified on the purchase order with a tolerance of +/- 10% unless otherwise stated on the order.
2. Packaging
Foil rolls are to be packed in standard export wooden box,normal handling by common carrier will ensure safe transportation without damage to the foil. This includes wrapping to protect the foil from water stain and corrosion.
