Aluminum Discs Blank For Spinning Specification:
| Products Name | Alloy | Purity | Hardness | Specification | |
| Thickness | Diameter | ||||
| Aluminum Discs | 1050, 1070, 3003 | 96.95-99.70% | O, H12, H14 | 0.5-4.5 | 90-1020 |
Alloy: 1050, 1060, 1070, 1100, 3002, 3003, 3004, 5052A, 5052, 5754, 6061
Hardness: O, H12, H14, H16, H18
Thickness: 0.3-10 mm
Diameter: 100-1500 mm
Surface: Polished, Bright, Anodized
Usage: Suitable for making pots, pans, pizza trays, pie pans, cake pans, covers, kettles, basins, fryers, light reflectors
Stamping: Materials include: steel, galvanized steel, aluminum, aluminum alloy and other metal.
Aluminium Circle Blank Chemical Composition
| Alloy | Si | Fe | Cu | Mn | Mg | Cr | Ni | Zn | Ca | V | Ti | Other | Min Al |
| 1050 | 0.25 | 0.40 | 0.05 | 0.05 | 0.05 | – | – | 0.05 | – | 0.05 | 0.03 | 0.03 | 99.50 |
| 1070 | 0.25 | 0.25 | 0.04 | 0.03 | 0.03 | – | – | 0.04 | – | 0.05 | 0.03 | 0.03 | 99.70 |
| 3003 | 0.60 | 0.70 | 0.05-0.20 | 1.00-1.50 | 0.03 | – | – | 0.10 | – | – | – | 0.15 | 96.75 |
Aluminium Discs Blank Mechanical Properties
| Temper | Thickness(mm) | Tensile Strength | Elongation(%) | Standard |
| O | 0.4-6.0 | 60-100 | ≥ 20 | GB/T3190-1996 |
| H12 | 0.5-6.0 | 70-120 | ≥ 4 | |
| H14 | 0.5-6.0 | 85-120 | ≥ 2 |
Aluminium Circle Blank Specification Tolerance
| Blanked and Sheared Circle Products | |||
| Thickness(mm) | Diameter Range (D)(mm) | ||
| 0.5-4.5 | D ≤ 455 | 455< D ≤ 1000 | 1000< D ≤ 1200 |
| +/- 0.079 | +/- 0.099 | +/- 0.015 | |
| The max dimension may vary according to individual specifications | |||
Aluminium Circle For Spinning Features
1.Quality assured
2.Longer shelf life
3.Precisely shaped
