The Processing Of Electronic Aluminum Foil For The Production Of Capacitors
Aluminum foil for electronicis generally subjected to surface corrosion treatment and oxidation treatment, and then coiled, and finally made into a capacitor.
The aluminum foil before corrosion is called light foil, and the aluminum foil after corrosion is called corrosion foil. Electronic aluminum foil has higher corrosion requirements for material structure.
Professional Electronic Aluminum Foil Manufacturer
The 1000 series and 3000 series aluminum alloys produced by Henan Huawei can be used in the manufacture of electronic foils, and commonly used are 1070, 1100A, and 3003 aluminum foils.
Manufacturer of Aluminum Foil for Electronics
Classification And Thickness Of Electronic Aluminum Foil
Electronic aluminum foil can be divided into high-voltage anode foil, low-voltage anode foil, cathode foil, etc. Among them, the high-voltage and low-voltage anode foil (formed foil) requires an aluminum purity of more than 99.99%.
The Thicknesses Of Aluminum Foil For Electronic
High voltage anode foil: thickness 0.065mm to 0.1mm.
Low-voltage anode foil: thickness 0.06mm to 0.1mm.
Cathode foil: 0.015mm to 0.06mm thick
Parameters Of Aluminum Foil For Electronic
Alloys: 1050, 1060, 1070, 1100, 1235, 3003 etc
Tempers: H18, soft HO ( h0 ).
Other special specifications according to customer's requirements.
The Parameter Chart Of The Electronic Aluminum Foil Huawei Aluminum Provide |
|
| Typical alloy | 3003, 1070, 1100A |
| Temper | H18 |
| Thickness (mm) | 0.015-0.2 |
| Width (mm) | 100-1600 |
| Length (mm) | Coil |
| Treatment | mill finish |
| Standard | ISO SGS ASTM ENAW |
| Price terms | LC/TT/DA/DP |
| Packaging | Standard seaworthy export packaging. Wooden pallets with plastic protection for the coil and sheet. |
Applications Of Aluminum Foil For Electronic
According to the end-user, it can be divided into
Aluminum foil for battery ( battery cell, lithium battery electrode, battery anode, battery bag, etc )
Aluminum foil for capacitance
Aluminum foil for LED ( led bulb, led base plate, etc)
Aluminum foil for air conditioner
